Lenovo Legion 5 Pro 16IAH7H GAMING Core™ i7-12700H 2TB SSD

Product type

Notebook

Product color

Gray

Form factor

Clamshell

Color name

Storm Grey

Housing material

Aluminum

Display diagonal

16"

Display resolution

2560 x 1600 pixels

Touchscreen

N

HD type

WQXGA

Panel type

IPS

LED backlight

Y

Native aspect ratio

16:10

Anti-glare screen

Y

Display brightness

500 cd/m²

RGB color space

sRGB

Color gamut

100%

Maximum refresh rate

165 Hz

Contrast ratio (typical)

1200:1

High Dynamic Range (HDR) supported

Y

High Dynamic Range (HDR) technology

DisplayHDR 400, Dolby Vision

Processor family

Intel® Core™ i7

Processor manufacturer

Intel

Processor model

i7-12700H

Processor generation

12th gen Intel® Core™ i7

Processor boost frequency

4.7 GHz

Processor cores

14

Processor cache

24 MB

Processor cache type

Smart Cache

Motherboard chipset

Intel SoC

Configurable TDP-down

35 W

Internal memory

32 GB

Maximum internal memory

32 GB

Internal memory type

DDR5-SDRAM

Memory clock speed

4800 MHz

Memory form factor

SO-DIMM

Memory layout (slots x size)

2 x 16 GB

Memory slots

2x SO-DIMM

Memory channels

Dual-channel

Total storage capacity

2000 GB

Storage media

SSD

Optical drive type

N

Total SSDs capacity

2000 GB

Number of SSDs installed

2

SSD capacity

1000 GB

SSD interface

PCI Express 4.0

NVMe

Y

SSD form factor

M.2

Card reader integrated

N

On-board graphics card

Y

Discrete graphics card

Y

Discrete graphics card model

NVIDIA GeForce RTX 3070 Ti

On-board graphics card model

Intel Iris Xe Graphics

Discrete GPU manufacturer

NVIDIA

Discrete graphics card memory

8 GB

Discrete graphics memory type

GDDR6

Audio chip

Realtek ALC3287

Audio system

Nahimic Audio

Number of built-in speakers

2

Speaker power

2 W

Built-in microphone

Y

Number of microphones

2

Front camera

Y

Front camera resolution

1280 x 720 pixels

Front camera HD type

HD

Privacy camera

Y

Privacy type

Privacy shutter

Mobile network connection

N

Top Wi-Fi standard

Wi-Fi 6E (802.11ax)

Wi-Fi standards

Wi-Fi 6E (802.11ax)

Antenna type

2x2

Ethernet LAN

Y

Ethernet LAN data rates

1000,100 Mbit/s

Bluetooth

Y

Bluetooth version

5.1

WWAN

Not installed

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

3

HDMI ports quantity

1

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity

2

Ethernet LAN (RJ-45) ports

1

Thunderbolt 4 ports quantity

1

Intel® Thunderbolt 4

Y

Combo headphone/mic port

Y

USB Type-C DisplayPort Alternate Mode

Y

USB Power Delivery

Y

USB Sleep-and-Charge

Y

USB Sleep-and-Charge ports

1

Numeric keypad

Y

Pointing device

Touchpad

Keyboard language

US English

Keyboard backlit

Y

Keyboard backlit color

RGB

Operating system installed

Windows 11 Pro

Operating system architecture

64-bit

Operating system language

English

Intel Flex Memory Access

Y

Intel Trusted Execution Technology

Y

Intel VT-x with Extended Page Tables (EPT)

Y

Execute Disable Bit

Y

CPU configuration (max)

1

Embedded options available

N

Intel Virtualization Technology for Directed I/O (VT-d)

Y

Intel Virtualization Technology (VT-x)

Y

Battery capacity

80 Wh

Battery technology

Lithium Polymer (LiPo)

Fast charging

Y

AC adapter power

300 W

AC adapter frequency

50 - 60 Hz

AC adapter input voltage

100 - 240 V

Fingerprint reader

N

Trusted Platform Module (TPM)

Y

Trusted Platform Module (TPM) version

2.0

Password protection

Y

Password protection type

BIOS, Power on, Supervisor, HDD

Operating temperature (T-T)

5 - 35 °C

Storage temperature (T-T)

5 - 43 °C

Operating relative humidity (H-H)

8 - 95%

Storage relative humidity (H-H)

5 - 95%

Maximum shipping altitude

120000" (3048 m)

Certification

TÜV

Sustainability certificates

RoHS, ErP

Weight

5.49 lbs (2.49 kg)

Width

14.2" (359.9 mm)

Depth

10.4" (264.4 mm)

Height

0.783" (19.9 mm)
